    ASTM G154 UV Lamp Environment Test Machine Program Controllable

    Ask Lasest Price
    Brand Name : ZL
    Model Number : ZL-6009
    Certification : CE,ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 60 Sets
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    ASTM G154 UV Lamp Environment Test Machine Program Controllable

    ASTM G154 UV Lamp Environment Test Machine Program Controllable
    This machine promotes the deterioration of vulcanite and calculates the change rate of tensile strength and elongation. It simulates sun and heat effects using ultraviolet radiation, allowing observation of sample resistance to yellowing and discoloration. The equipment features a UV lamp (300W) for accelerated testing and can function as both an aging test machine and oven, offering multi-functional capabilities. A forced hot air circulation control system ensures uniform temperature distribution.
    ZL-6009A Aging Anti-Yellow Testing Machine Documentation
    Working Principle
    The internal mixer operates with two rotors rotating relative to each other, feeding materials into the roll gap where they undergo squeezing and shearing. Materials cycle around the rotor, experiencing shear and friction that raises temperature, reduces viscosity, and enhances wettability. Compounding agents are sheared and broken through gaps, while rotor convex edges provide axial movement for thorough mixing. This process ensures even dispersion of compounding agents in the rubber material.
    Compliance Standards
    CNS-3556, JIS-K6301, ASTM-D2436, ASTM D1148, BS 5131, ASTM D573
    Applicable Industries
    Widely used in paint, resins, plastics, printing and packaging, aluminum, adhesives, automotive, cosmetics, metals, electronics, electroplating, medicine, and more.
    Technical Parameters
    ModelZL-6009A
    Inside Size40×40×45cm
    Volume91×55×100cm
    TemperatureRoom temp ~ 200℃
    Temperature Resolution0.1 degree
    Accuracy±1 degree
    Timer0-999H, memory-type with buzzer
    Control ModeAutomatic calculation controller
    Wheel SpeedDia.45cm, 10R.P.M. ±2R.P.M
    UV LampUV300W
    HeatingHot loop
    ProtectionEGO over-temperature guiding light, overload switch ammeter
    MaterialInside SUS#304 stainless steel, outside high-level paint
    Weight87kg
    Power1∮, AC220V, 19.5AC
    ASTM G154 UV Lamp Environment Test Machine
    Frequently Asked Questions
    • How about your warranty?
      Generally, our warranty is two years. Within the warranty period, we offer technical support and replacement parts. When necessary, our engineers may provide on-site service.
    • How about the packing for machine, is it safely protected during transportation?
      Our machines are packed in standard export wooden boxes to prevent damage. We have extensive experience delivering testing machines internationally by sea and air without issues.
    • What is the order process?
      Inquiry → Quotation → Communication → Order Confirmation → Deposit Payment → Production → Testing and Debugging → Balance Payment → Packing → Delivery → Customer Receiving → After Service.
    • How to install and use the product?
      The product ships with English version operating instructions and installation videos.
