Floor-standing Single Column Microcomputer Material Testing Machine
Equipment summary:
ZL-8003A Microcomputer economic material testing machine is a new
material testing machine that combined with the electronic
technology and mechanical transmission, it has accurate load speed,
range of force measurement, Has high accuracy and sensitivity for
the load, displacement measurement and control, This machine is
simple to operate, simple structure, it can be directly placed on
the testing table for test, especially suitable for controlling
quality in production line This series of machine is mainly applied
to test the non-metallic and metallic materials which the load is
less than 5KN.
ZL-8003A
Microcomputer type economic type material...
Imported photoelectric encoder is used for displacement
measurement, and the controller adopts embedded single-chip
microcomputer structure, built-in powerful measurement and control
software, and integrates measurement, control, calculation, and
storage functions. With automatic calculation of stress, elongation
(extensometer required), tensile strength, modulus of elasticity,
automatic statistical results; automatic recording of the maximum
point, breaking point, designated point force value or elongation;
use a computer for testing Dynamic display of process and test
curve, and data processing. After the test, the graph processing
module can be used to enlarge the curve for data re-analysis and
editing, and the report can be printed. The product performance has
reached the international advanced level.
Main functions:
This machine can be test all the material in tensile, compression,
bending, shear, peel, tear, two-point extended (need add
extensometer) and others for control products quality. Such as
textile, rubber, plastics, synthetic leather, tape, adhesive,
plastic film, composite materials, electronics, metals and other
materials.
Main feature
1. The surface of appearance using electrostatic spray, simple and
generous, multi-functions and economy
2. Digital force displayed by LCD , discernible tension or
pressure, LCD display clearly
3. Three kinds of units: N,Kg,Lb,Ton option or automatically
exchange;
4. LCD with backlight can be used in low-light environments
5. Single measurement, it can record the max force of tension and
compression in both directions, automatic or manual cleared to
zero.
6. The system would shut down if overload or over-trip
7. Structure of single-column is beautiful, sophisticated and
economy.
Corresponding standard:
Applicable industry:
It is widely used in wire and cable, hardware, electronic and
electrical equipment, packaging, printing, medical equipment, auto
parts, textiles and leather, clothing, shoes, rubber and plastic
products, colleges and universities; research laboratories;
inspection arbitration, technical supervision departments and many
other industries, it is the basic equipment for quality management
and physical tested
Technical parameter:
| Max. load | 5KN |
| Max. stroke | 800mm |
| Length of the pillar | 1000mm |
| Test the rated speed | 0.001～500mm/min |
| Dimension | 450×550×1400mm (H×W×D) |
| Weight | About 150kg |
| Power | AC 220V |
Original configuration:
A group of tensile fixture
